Cast Aluminum Intake Manifold for longitudinal VW/AUDI 1.8T with 8 injectors Fuel Rail Kit (without throttle bolt holes) - PRE SALE
Cast Aluminum Intake Manifold for longitudinal VW/AUDI 1.8T with 8 injectors Fuel Rail Kit (without throttle bolt holes) - PRE SALE is backordered and will ship as soon as it is back in stock.
Couldn't load pickup availability



Take advantage of this great opportunity and buy this product at an unbeatable price! This item will be available for delivery approximately 07/31/2025.
SPA Turbo’s intake manifold was designed for upgrades builds, having a bigger plenum volume and allowing higher airflow, it is the perfect solution for those who wants high performance and durability, guaranteed by the cast aluminum construction. Available in 4 or 8 injectors with anodized aluminum fuel rails. In addition, you can choose between an OEM throttle body bolt holes pattern or without holes, for those who wants to use a different throttle body (up to 80mm).
Application: VW Passat 1.8 20V Turbo / Audi A4 / A6 1.8 20V Turbo (Large Port head)
Number of injectors: 8
Fuel rail: anodized aluminum, -8AN inlet/outlet
Throttle body position (TBI): side (not OEM)
Injectors compatible: Bosch style, 14mm o-ring, compact / standard / long
Throttle body bolt holes pattern: without throttle bolt holes
Max pressure capacity: 10bar (145psi)
Internal volume: 3,2L
Material: cast aluminum
Ports: stock temperature sensor, 1/8” NPT (5x), -6AN (1x)
Supplied coolant pipe was designed to replace the stock 06B 121 070H, which must be used with hose 06B 121 132 and coolant flange 06B 121 101.
*Note: water pipe features a -6AN port for turbo water cooling, fitting not included.
Description
Description
Take advantage of this great opportunity and buy this product at an unbeatable price! This item will be available for delivery approximately 07/31/2025.
SPA Turbo’s intake manifold was designed for upgrades builds, having a bigger plenum volume and allowing higher airflow, it is the perfect solution for those who wants high performance and durability, guaranteed by the cast aluminum construction. Available in 4 or 8 injectors with anodized aluminum fuel rails. In addition, you can choose between an OEM throttle body bolt holes pattern or without holes, for those who wants to use a different throttle body (up to 80mm).
Application: VW Passat 1.8 20V Turbo / Audi A4 / A6 1.8 20V Turbo (Large Port head)
Number of injectors: 8
Fuel rail: anodized aluminum, -8AN inlet/outlet
Throttle body position (TBI): side (not OEM)
Injectors compatible: Bosch style, 14mm o-ring, compact / standard / long
Throttle body bolt holes pattern: without throttle bolt holes
Max pressure capacity: 10bar (145psi)
Internal volume: 3,2L
Material: cast aluminum
Ports: stock temperature sensor, 1/8” NPT (5x), -6AN (1x)
Supplied coolant pipe was designed to replace the stock 06B 121 070H, which must be used with hose 06B 121 132 and coolant flange 06B 121 101.
*Note: water pipe features a -6AN port for turbo water cooling, fitting not included.
